Durable Electric Turbine Control Valve High Pressure PLC Water Level Sensor

High Pressure PLC Water Level Sensor Electric Turbine Control Gate Valve For Hydro Turbine

Product Features

1. The electrical control system adopts PLC intelligent control, which greatly simplifies the electrical circuit and has strong fault self-diagnosis function. Can be local, remote control, by the central control room and linkage control with the turbine, high degree of automation, safe and reliable, to achieve the power station "few people on duty and no

The management concept of "people at work";

2. The hydraulic control system USES heavy hammer or accumulator to store energy. When the hydropower station is out of power, the heavy hammer or accumulator releases energy, which can realize emergency dynamic water shutoff gate valve and provide sufficient safety guarantee for the safe operation of the unit.

3. The electrical control box can be installed as a whole with the hydraulic station or arranged separately, depending on the field conditions;

4. The sealing surface of the main valve is a double-sided sealing structure of cemented carbide seal, which is easy to open and close and reliable to seal on the liquid control actuator developed by Shanghai fuyaohe; So that the valve has a good self-closing, self-sealing performance. Large diameter gate structure, small crowding, smooth flow, valve flow resistance coefficient is only 0.15 ~ 0.8, far less than the check valve flow resistance coefficient (1.7 ~ 2.6), energy saving effect is obvious.

5, valve body adopts integral casting, high strength, good sealing performance;

6. The bypass pipeline is equipped with manual maintenance valve, expansion joint and electric valve, among which the electric valve can be replaced by liquid control valve, and linkage control with the main valve.

7. The downstream connection pipe can be equipped with air valve and sewage valve, which can be determined according to customer and site requirements.

Running program:

Valve opening: open bypass valve → differential pressure balance → open main valve → close bypass valve

Valve closing: open bypass valve → close main valve → close bypass valve

Product pictures:

turbine governor valve

water pressure regulator valve

Durable Electric Turbine Control Valve High Pressure PLC Water Level Sensor Images
